2.3 Dimension Drawing
 If you add optional parts to the inverter, some extra
space is required in the direction of the depth of the
inverter depending on the wiring layout. Keep a
clearance of 50 mm or more. For details, refer to the
instruction manual for each optional product.
Model(LH1-***H)
400V Class : 055H
Dimension
W(mm)
H(mm)
D(mm)
150
255
140
、
Model (LH1-***H)
400V Class : 185H/220H/300H
Dimension
W(mm)
H(mm)
D(mm)
245
390
190
(Eg.) See "Chapter 7 Specifications" for details.
Model (LH1-***H)
400V Class : 370H
Dimension
W(mm)
H(mm)
D(mm)
300
540
195
Model (LH1-***H)
400V Class : 075H/110H/150H
Dimension
W(mm)
H(mm)
D(mm)
210
260
170
540
510 6
265
300
195
2.3
2-φ10
10
15
265
246
189
210
7
170
70
1.6
2-φ7
376
245
7
2-7×9.5 long hole
84
190
229
255
6
150
241
140
47
3
2-φ6
130
260
390
1.6
