PJ-TX100W/E/U ver 1.2
9
3. IMAGE QUALITY
Apply following condition except where noted.
• Apply heat-running for 10 minutes or more before checking
• Ambient temperature is 23 °C
• Whisper: Normal,
•Gamma: Default #1
•Temp: Custom (offset 0, gain 0)
• Vertical Lens shift: 1:1, Horizontal Lens shift: 1:1
• Zoom: Wide max, Foot adjust: Retracted (Set should be even with the ground.
3.1 BRIGHTNESS
960 lumens minimum
(Note 1) ANSI 9 point Standard measurement at Screen size 40inch, Meter CL-200
Brightness = Luminance intensity averaged over 9 points x screen area
Typical 1200 lumens (Target)
Brightness: Max. Contrast: Max.
3.2 BRIGHTNESS UNIFORMITY
BRIGHTNESS UNIFORMITY 60% minimum, 70% typical (Target)
(Note) ANSI Standard measurement
Brightness uniformity = Minimum of the four corner measurements/average of 9 points measurements
Zoom position: wide, Brightness/Contrast; Default setting
1/6W1/3W
1/6H
1/3H
To Next Page
