Hitachi PJ-TX100 Product Specifications

PJ-TX100W/E/U ver 1.2
3
R.G.B in (RGB)
15 Pin D-Sub Pin assignments
NO. RGB Component Video NO. RGB Component Video
1 Red Cr/Pr 9 N.C. PLUG DETECT
2 Green Y 10 GND GND
3 Blue Cb/Pb 11 N.C. ID3
4 N.C. ID1 12 SDA (DDC) NC
5 GND GND 13 H/Composite Sync NC
6 GND(Red) GND(Cr/Pr) 14 Vsync ID2
7 GND(Green) GND(Y) 15 SCL (DDC) NC
8 GND(Blue) GND(Cb/Pb)
Control (RS232C)
9 Pin D-sub Pin assignments
1
2 RD
3
TD
4
5 GND
6
7
RTS
8
CTS
9
DVI-D
PIN No. TIRMINAL PIN No. TIRMINAL
1
TMDS DATA 2−
13 NC (TMDS DATA 3+)
2
TMDS DATA 2＋
14
＋5V POWER
3 GND(TMDS DATA 2/4SHIELD) 15 GND
4
NC (TMDS DATA 4−)
16 HOT PLUG
5
NC (TMDS DATA 4＋)
17
TMDS DATA 0−
6 DDC CLK 18
TMDS DATA 0＋
7 DDC DATA 19 GND(TMDS DATA 0/5 SHIELD)
8 ANALOG V SYNC 20
NC (TMDS DATA 5−)
9
TMDS DATA 1−
21
NC (TMDS DATA 5＋)
10
TMDS DATA 1＋
22 GND (TMDS CLK SHIELD)
11 GND (TMDS DATA 1/3 SHIELD) 23
TMDS CLK ＋
12
NC (TMDS DATA 3−)
24
TMDS CLK −
1.16 POWER SUPPLY AC90 ~ 132V / AC198 ~ 264V (50/60Hz), 3 Wire Grounded
1.17 POWER CONSUMPTION 100 ~ 120V/220 ~ 240V, 50/60Hz 2.4 /1.3A typ., Max. + 10%
100V, 50/60Hz, 220W typ., Max. + 10%
1.18 DIMENSIONS 340X110X280 mm, 13.4X4.3X11.0 inch.(WXHXD)
Excluding extrusions
1.19 WEIGHT 4.4 kg, 9.7lbs
