Hitachi PJ-TX100 Product Specifications

PJ-TX100W/E/U ver 1.2
12
4. ELECTRICAL
4.1 VIDEO SIGNAL INPUT
(1) Composite
Amplitude 1.0 ± 0.1 Vp-p at 75 Ω
terminated
Input impedance 75Ω
(2) S-VIDEO
Amplitude Y: 1.0 ± 0.1 Vp-p at 75 Ω
terminated with composite sync
C: 0.3 ± 0.1 Vp-p at 75 Ω
terminated
Input impedance 75Ω
(3) Component
Amplitude Y: 1.0 ± 0.1 Vp-p at 75 Ω
terminated with composite sync
C
B
/P
B
,C
R
/P
R
: 0.7± 0.1 Vp-p at 75 Ω terminated
Input impedance 75 Ω
4.2 RGB SIGNAL INPUT
(1) Analog RGB
Amplitude 0.7 ± 0.1 Vp-p at 75 Ω
terminated
Input impedance 75 Ω
(2) Sync. TTL level
(3) Computer compatibility
Resolution H x V Refresh Rate Horizontal Frequency Standard Type Note
640x480 59.9 Hz 31.5 kHz VESA VGA-3
640x480 66.7 Hz 35.0 kHz Mac 13"
640x480 72.8 Hz 37.9 kHz VESA
640x480 75.0 Hz 37.5 kHz VESA
640x480 85.0 Hz 43.3 kHz VESA
640x480 120.0Hz 61.8 kHz
800x600 56.3 Hz 35.2 kHz VESA
800x600 60.3 Hz 37.9 kHz VESA
800x600 72.2 Hz 48.1 kHz VESA
800x600 75.0 Hz 46.9 kHz VESA
800x600 85.1 Hz 53.7 kHz VESA
800x600 120.0 Hz 77.2kHz
832x624 74.5 Hz 49.7 kHz Mac 16"
1024x768 60.0 Hz 48.4 kHz VESA
1024x768 70.1 Hz 56.5 kHz VESA
1024x768 75.0 Hz 60.0 kHz VESA
1280x960 60.0 Hz 60.0 kHz VESA
1280x1024 60.0 Hz 64.0 kHz VESA
Note: SVGA/XGA /SXGA input signals shall be displayed but picture quality might be rude.

Hitachi PJ-TX100 Specifications

General

Brand	Hitachi
Model	PJ-TX100
Category	Projector
Language	English
