Hitachi S1 Series User Manual

S1 series standard inverter
-154-
Function
code
Name
Detailed parameter description
Default
value
Modify
P28.15
AD sampling
value of AI2 given
voltage 2
0–4095
0
○
P28.16
AD sampling
value of AI3 input
voltage
0.00–10.00s
0.00s
●
P28.17
AI3 given voltage
1
-10.00–1.00V
-10.00V
○
P28.18
AD sampling
value of AI3 given
voltage 1
0–4095
0
○
P28.19
AI3 given voltage
2
4.00–10.50V
10.00V
○
P28.20
AD sampling
value of AI3 given
voltage 2
0–4095
0
○
P28.21
Actual voltage
value of AO1
reletive to 0V
-1.000–12.500V
-0.200V
○
P28.22
Actual voltage
value of AO1
reletive to 10V
-1.000–12.500V
10.250V
○
P28.23
Actual voltage
value of AO1
reletive to 0mA
-1.000–12.500V
-0.200V
○
P28.24
Actual voltage
value of AO1
reletive to 20mA
-1.000–12.500V
10.250V
○
P29 group Factory function
P29.00
Password
0–65535
*****
○
P29.01
Reserved
0–1
0–1
●
P29.02
Inverter type
0–33
Depend
on
model
◎
P29.03
Inverter rated
power
0.4–3000.0kW
Depend
on
model
●
P29.04
Inverter rated
0–1200V
Depend
◎

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
