S1 series standard inverter
-196-
by the master):
Parameter
address
Inverter
address
Write
command
CRC
Parameter
data
03 06 00 03 27 10 62 14
Note: In the preceding command description, spaces are added to a command just for explanatory
purposes. In practical applications, no space is required in the commands.
9.4.8.3 Continuously write command 10H examples
Example 1: Set the inverter whose address is 01H to be forward running at the frequency of 10 Hz.
Refer to the table of other function parameters, the address of "Communication-based control
command" is 2000H, 0001H indicates forward running, and the address of "Communication-based
value setting" is 2001H, as shown in the following figure. 10 Hz is 03E8H in the hexadecimal form.
Communication-based
control command
0006H: Coast to stop (emergency stop)
Communication-based
value setting
Communication-based frequency setting (0–
Fmax, unit: 0.01 Hz)
PID setting, range (0–1000, 1000 corresponding
to 100.0%)
In the actual operation, set P00.01 to 2 and P00.06 to 8.
The command transmitted by the master is as follows:
Parameter
address
Inverter
address
Continuous
write
command
Number of
bytes
Parameter
quantity
01 10 20 00 00 02 04
Froward
running
00 01
10 Hz
03 E8
CRC
3B 10
If the operation is successful, the following response is returned:
Parameter
address
Inverter
address
Continuous
write
command
CRC
Parameter
quantity
01 10 20 00 00 02 4A 08
Example 2: Set "Acceleration time" of the inverter whose address is 01H to 10s, and "Deceleration
time" to 20s.
