S1 series standard inverter
-207-
D1
W2
W1
H2H1
W3
Fig 11.7 Wall-mounting diagram of inverters of 400 V, 45 to 75 kW
H2H1
W2
D1
W1
Fig 11.8 Wall-mounting diagram of inverters of 400 V, 90 to 110 kW
