Hitachi S1 Series

S1 series standard inverter
-208-
W1
H1
D1 W2 W2
6- Φ11.0
H2
Fig 11.9 Wall-mounting diagram of inverters of 400 V, 132 to 200 kW
W2
6- Φ13.0
H2
D1
W2
Fig 11.10 Wall-mounting diagram of inverters of 400 V, 220 to 315 kW
Wall-mounting dimensions of 400 V inverters (unit: mm)
Inverter
specification
W1
W2
W3
H1
H2
D1
Installation
hole
diameter
Fixing
screw
4kW -5.5kW
126
115
-
186
175
201
5
M4
7.5kW
146
131
-
256
243.5
192
6
M5
