Hitachi S1 Series User Manual

S1 series standard inverter
-27-
Terminal
name
Technical specifications
Voltage range: 12–24V
Y1
1. Contact capacity: 50mA / 30V
2. Output frequency range: 0 – 1kHz
+24V-H1
1. Safe torque off (STO) redundant input, connect to external NC contact, STO acts
when the contact opens, and the inverter stops output
2. Safety input signal wires use shielded wire whose length is within 25m
+24V-H2
+ 24V
The inverter provides user power; the maximum output current is 200mA
COM
Common port of + 24V
+ 10V
10V reference power supply
Max. Output current: 50mA
AI2
1. Input range: AI2 voltage and current can be chosen: 0 – 10V / 0 – 20mA; AI3: -10V
– + 10V
2. Input impedance: voltage input: 20kΩ; current input: 500Ω
3. Voltage or current input can be set by toggle switch
4. Resolution: the minimum AI2 / AI3 is 10mV / 20mV when 10V corresponds to
50Hz
AI3
GND
Analog reference ground
AO1
1. Output range: 0 – 10V voltage or 0 – 20mA current
2. Voltage or current output is set by toggle switch
3. Error ± 1%, 25 ° C
RO1A
1. Contact capacity: 3A / AC250V, 1A / DC30V
2. Please note that it should not be used as high frequency switch output
RO1B
RO1C

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
