Hitachi S1 Series User Manual

S1 series standard inverter
-77-
Function
code
Name
Detailed parameter description
Default
value
37: Command switches to terminal
38: Command switches to
communication
39: Pre-exciting command
40: Zero out power consumption
quantity
41: Maintain power consumption
quantity
42: Emergency stop
61: PID polarity switch-over
P05.08
Polarity of input terminal
0x00–0x3F
0x00
P05.09
Digital filter time
0.000–1.000s
0.010s
P05.10
Virtual terminal setting
0x00–0x3F (0: disable, 1: enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDI/HDIA virtual terminal
BIT5: HDIB virtual terminal
0x00
P05.11
2/3-wire control mode
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
0
P05.12
S1 terminal switch-on delay
0.000–50.000s
0.000s
P05.13
S1 terminal switch-off delay
0.000–50.000s
0.000s
P05.14
S2 terminal switch-on delay
0.000–50.000s
0.000s
P05.15
S2 terminal switch-off delay
0.000–50.000s
0.000s
P05.16
S3 terminal switch-on delay
0.000–50.000s
0.000s
P05.17
S3 terminal switch-off delay
0.000–50.000s
0.000s
P05.18
S4 terminal switch-on delay
0.000–50.000s
0.000s
P05.19
S4 terminal switch-off delay
0.000–50.000s
0.000s
P05.20
HDI/HDIA terminal switch-on
delay
0.000–50.000s
0.000s
P05.21
HDI/HDIA terminal switch-off
delay
0.000–50.000s
0.000s
P05.22
HDIB terminal switch-on delay
0.000–50.000s
0.000s

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
