Hitachi S1 Series User Manual

S1 series standard inverter
-79-
Set
value
Function
Description
8
Frequency reached
Refer to P08.36
9
Running in zero speed
Output ON signal when the inverter output frequency and
reference frequency are both zero.
10
Reach upper limit
frequency
Output ON signal when the running frequency reaches
upper limit frequency
11
Reach lower limit
frequency
Output ON signal when the running frequency reached
lower limit frequency
12
Ready to run
Main circuit and control circuit powers are established,
the protection functions do not act; when the inverter is
ready to run, output ON signal.
13
In pre-exciting
Output ON signal during pre-exciting of the inverter
14
Overload pre-alarm
Output ON signal after the pre-alarm time elapsed based
on the pre-alarm threshold; see P11.08–P11.10 for
details.
15
Underload pre-alarm
Output ON signal after the pre-alarm time elapsed based
on the pre-alarm threshold; see P11.11–P11.12 for
details.
23
Virtual terminal output of
Modbus communication
Output corresponding signal based on the set value of
Modbus; output ON signal when it is set to 1, output OFF
signal when it is set to 0
24
Reserved variables
/
25
Reserved variables
/
26
DC bus voltage
established
Output is valid when the bus voltage is above the
undervoltage threshold of the inverter
27
STO action
Output when STO fault occurred
Related parameter list:
Function
code
Name
Detailed parameter description
Default
value
P06.00
HDO output type
0: Open collector high-speed pulse output
1: Open collector output
0
P06.01
Y output selection
0: Invalid
1: In running
2: In forward running
3: In reverse running
4: In jogging
5: Inverter fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
0
P06.02
HDO output selection
0
P06.03
Relay RO1 output
selection
1
P06.04
Relay RO2 output
selection
5

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
