Hitachi S1 Series User Manual

S1 series standard inverter
-80-
Function
code
Name
Detailed parameter description
Default
value
8: Frequency reached
9: Running in zero speed
10: Reach upper limit frequency
11: Reach lower limit frequency
12: Ready to run
13: In pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16 – 17: Reserved
18: Reach set counting value
19: Reach designated counting value
20: External fault is valid
21: Reserved
22: Reach running time
23: Virtual terminal output of Modbus
communication
24 -25: Reserved
26: DC bus voltage established
27: STO action
48–63: Reserved
P06.05
Output terminal polarity
selection
0x00–0x0F
0x00
P06.06
Y switch-on delay
0.000–50.000s
0.000s
P06.07
Y switch-off delay
0.000–50.000s
0.000s
P06.08
HDO switch-on delay
0.000–50.000s (valid only when P06.00=1)
0.000s
P06.09
HDO switch-off delay
0.000–50.000s (valid only when P06.00=1)
0.000s
P06.10
Relay RO1 switch-on
delay
0.000–50.000s
0.000s
P06.11
Relay RO1 switch-off
delay
0.000–50.000s
0.000s
P06.12
Relay RO2 switch-on
delay
0.000–50.000s
0.000s
P06.13
Relay RO2 switch-off
delay
0.000–50.000s
0.000s
P07.40
Output terminal state of
present fault
/
0
P17.13
Digital output terminal
state
/
0

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
