S1 series standard inverter
-94-
Detailed parameter description
4: Set via high speed pulse HDIA
5: Reserved
6: Set via multi-step speed running
7: Set via PID control
8: Set via Modbus communication
9–15: Reserved
Note: for models 4kW and above
1: No function
2: AI1
3: AI2
Reference object
of B frequency
command
0: Max. output frequency
1: A frequency command
Combination
mode of setting
source
0: A
1: B
2: (A+B)
3: (A-B)
4: Max. (A, B)
5: Min. (A, B)
When A and B frequency commands are set by
keypad, the value is the initial digital set value of
the inverter frequency.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
Acceleration time is the time needed for
accelerating from 0Hz to Max. output frequency
(P00.03).
Deceleration time is the time needed from
decelerating from Max. output frequency (P00.03)
to 0Hz.
S1 series inverter defines four groups of
acceleration and deceleration time, which can be
selected via multi-function digital input terminals
(P05 group). The acceleration/deceleration time
of the inverter is the first group by default.
Setting range of P00.11 and P00.12: 0.0–3600.0s
0: Run in default direction
1: Run in reverse direction
2: Reverse running is prohibited
