Hitachi SJ300 Series

Chart 3
Screw diameter and terminal width
3.1 Intelligent Input Terminal
(1) Default settings
The eight input terminals 1 to 8 can be configured for any of 44different functions.
The J300 and the SJ300 have the same default setting for each version (E type, U type), but the
function codes and the symbols are different in some parts. Please see the chart 4 for the
default setting of the J300 and the SJ300.
Default setting
J300 SJ300
Terminal
number
Function name
( )=US ver.
Function
code
Symbol
( )=US ver.
Function
code
Symbol
( )=US ver.
1 Reset C0 RS (18) C001 RS (18)
2
Analog input
selection
C1 AT (16) C002 AT (16)
3 Jogging C2 JG (5) C003 JG (06)
4 Free-run stop C3 FRS (11) C004 FRS (11)
5
Second
acccel/decel
C4 CH1 (9) C005 2CH (09)
6
Multispeed (2)
(Unattended
start protection)
C5
CF2 (2)
(USP(13))
C006
CF2 (03)
(USP(13))
7 Multispeed (1) C6 CF1 (1) C007 CF1 (02)
8 Reverse C7 REV (0) C008 RV (01)
Chart 4
Default settings for intelligent input terminals
(2) Contact logic conversion
The intelligent input terminals of J300 and SJ300 default to NO contacts. Please refer to the
chart 5 for the logic conversion of the contacts in the case of the SJ300.
