Hitachi SJ300 Series

J300 SJ300
Function code
No. Name
Digital
operator
Remote Operator
Default
setting
Function
code
(Digital
operator)
Default setting
Remarks
1 Frequency source setting F9 F-SET-SELCT REM A001 02
2 Run command source setting F9 F/R-SELCT REM A002 02
3 Data command method - F-09 PARAM REM C070 02
4 Initialization mode (parameters or trip history) - F-38 INIT TCNT CNT b084 00
5 Debug mode enable - INIT DBGU OFF C091 00
6 Keypad RUN key routing F4 INIT DOPE FWD F004 00
7 Reset mode selection A86 INIT RESET ON C102 00
8 Base frequency setting 1 A62 F-00 F-BASE 60 A003 60
Base frequency setting 2 A62 F-BASE 60 A203 60
9 Maximum frequency setting 1 A63 F-01 F-MAX 60 A004 60
Maximum frequency setting 2 A63 F-MAX 60 A204 60
10 Start frequency adjustment A4 F-02 F-min 0.5 b082 0.50
11 AVR voltage select F11 F-03 AVR AC 200/400 A082 200/400
12 AVR function select - AVR AC ON A081 00
13 V/f characteristic curve selection 1 A0 F-04 CONTROL VC A044 00
V/f characteristic curve selection 2 A0 CONTROL VC A244 00
14 Auto-tuning setting A97 F-05 AUX AUTO NOR H001 00
15 Motor data selection 1 A98 AUX DATA TMO H002 00
Motor data selection 2 A98 AUX DATA TMO H202 00
16 Motor capacity setting 1 A1 AUX K Factor set H003 Factor set
Motor capacity setting 2 A1 AUX K Factor set H203 Factor set
17 Motor poles setting 1 A2 AUX P 4 H004 4
Motor poles setting 2 A2 AUX P 4 H204 4
18 Motor constant R1 1 - AUX R1 Factor set H020 Factor set
Motor constant R1 2 - AUX R1 Factor set H220 Factor set
19 Motor constant R2 1 - AUX R2 Factor set H021 Factor set
Motor constant R2 2 - AUX R2 Factor set H221 Factor set
20 Motor constant L 1 - AUX L Factor set H022 Factor set
Motor constant L 2 - AUX L Factor set H222 Factor set
21 Motor constant M 1 - AUX M Factor set H023 Factor set Io is set in the case of the SJ300.
Motor constant M 2 - AUX M Factor set H223 Factor set
22 Motor constant J 1 - AUX J Factor set H024 Factor set
Motor constant J 2 - AUX J Factor set H224 Factor set
23 Speed response proportional constant Kp 1 A3 AUX Kp 2.00 H050 100.0
Speed response proportional constant Kp 2 A3 AUX Kp 2.00 H250 100.0
Motor proportional gain constant setting in the case of the
SJ300.
24 Option constant Ti 1 - AUX Ti 100ms H051 100.0
Option constant Ti 2 - AUX Ti 100ms H251 100.0
Motor integral gain constant setting in the case of the SJ300.
Option constant Kpp 1 - AUX Kpp 1.00 H052 1.00
Option constant Kpp 2 - AUX Kpp 1.00 H252 1.00
25 Carrier frequency setting A10 F-36 CARRIER Factor set b083 Factor set Please refer to 4.3 Carrier Frequency.
J300 SJ300No. Name
Function code Default Function Default setting
Remarks
19/24
