Hitachi SJ300 Series

Dimension comparison (Unit:mm)
Applicable Model Dimension Model Dimension
Difference in
dimension
motor (kW) J300 W H D SJ300 W H D W H D
1.5
to
5.5
015L
to
055L
015L
to
055L
150 255 140 -70 -85 -55
7.5 075L
220 340 195
075L -10 -80 -25
11 110L 110L
210 260 170
-40 -180 -50
15 150L
250 440 220
150L 0 -50 -30
18.5 185L
22
220L 300 450 250
220L
250 390 190
-50 -60 -60
30 300L 300L 310 540 195 -80 -80 -135
37 370L
390 620 330
370L 0 -70 -80
45 450L 450L
390 550 250
-90 -150 -80
55 550L
480 700 330
550L 480 700 250 0 0 -80
Chart 1
Comparison of dimensions
Applicable Model Dimension Model Dimension
Difference in
dimension
motor(kW) J300 W H D SJ300 W H D W H D
1.5
to
5.5
015H
to
055H
015H
to
055H
150 255 140 -70 -85 -55
7.5 075H
220 340 195
075H -10 -80 -25
11 110H 110H
210 260 170
-40 -180 -50
15 150H
250 440 220
150H 0 -50 -30
18.5 185H
22
220H 300 450 250
220H
250 390 190
-50 -60 -60
30 300H 300H 310 540 195 -80 -80 -135
37 370H
390 620 330
370H 0 -70 -80
45 450H 450H
55 550H
480 700 330
550H
390 550 250
-90 -150 -80
75 750H 750H
90 900H
480 700 270
900H
390 700 270 -90 0 0
110 1100H 550 780 270 1100H -70 -40 0
132
1320H
(UL ver.)
680 995 360
1320H
/1500H
480 740 270
-200 255 -90
Chart 2
Comparison of dimensions
