Chapter 4: Service processor
The VSP Fx00 models include an optional, separate 1U service processor (SVP) dedicated
to host an element manager (Storage Navigator). The SVP operates independently from
the CPU of the storage system and operating system, and provides out‑of‑band
conguration and management of the storage system. The SVP also monitors and
collects performance data for key components of the storage system to enable
diagnostic testing and analysis for customer support.
The SVP is also available as a 64-bit software application provided by Hitachi Vantara. For
the latest interoperability updates and details, see the SVP (Service Processor) OS and
Hypervisor support for Gx00, Fx00 report at
https://support.hitachivantara.com/en_us/
interoperability.html.
Service Processor (Windows 10 Enterprise) hardware
specifications
The following table lists the hardware specications for the service processor (Windows
10 Enterprise) provided by Hitachi Vantara.
Item Specification
Dimensions Height: 1.7 inches (43 mm)
Width: 17.2 inches (437 mm)
Depth: 9.8 inches (249 mm)
Weight: 10 lbs (4.5 kg)
Processor Intel N3710 Pentium processor 4C/4
threads 1.6 GHz 2M cache, 6W
Memory 2 x 4 GB DDR3 1600MHz
Storage media 1 TB 5400 RPM SATA HDD
LAN/Network interface card 1-GbE x 4 ports (on-board NIC)
x1 IPMI (BMC) port
Fans 2 x 4028 mm 13KPRM 4-pin PWM fans
Operating system Windows 10 Enterprise
Maximum temperature Up to 40° C (104° Fahrenheit)
Chapter 4: Service processor
Hitachi Virtual Storage Platform F700 Hardware Reference Guide 35
