Rail kit Hitachi Universal V2 Rack Third-party rack
2. CGR: Corner guide rail kit A3BF-HK-GL-740-1.
Hitachi Universal V2 Rack accessories
The following table provides rack accessory information for VSP G series storage
systems.
Table 34 Accessories for the Hitachi Universal V2 Rack
Storage system Front door Rear door Side panels
VSP Gx00 models Optional, must be
ordered separately
(A3BF-DR).
Included with rack Not included with
rack, must be
ordered separately.
A quantity of two
must be ordered
per rack (A3BF-Z-
PAN-1200).
Third-party rack support for DB60 dense intermix drive trays
Due to the size and weight of the DB60 dense intermix drive trays used with VSP Gx00
models, pay close special attention when mounted in third-party racks.
When mounting DB60 dense intermix drive trays in third-party racks, observe the
following guidelines and see the following gure.
■
Use anti-tilt oor plates or ceiling-mounted xing brackets to stabilize the rack.
■
Use a rack that is at least 40.94 in. (1040 mm) deep to accommodate the DB60 dense
intermix drive tray and cable-management arms.
■
Dense tray rail kits require square mounting holed racks.
■
Use a ladder to service the DB60 dense intermix drive tray if the drive tray is mounted
above shelf height RU32.
Hitachi Universal V2 Rack accessories
Appendix F: Non-Hitachi racks
Hitachi Virtual Storage Platform G350, G370 Hardware Reference Guide 127
