Hitachi Virtual Storage Platform G400 Reference Guide

• 16-Gbps Fibre Channel (4-port): 56 ports per system (or 64 ports per
systems for systems without drives or 24 ports per systems when NAS
Modules are installed)
• 32-Gbps Fibre Channel (4-port): 56 ports per system (or 64 ports per
systems for systems without drives or 24 ports per systems when NAS
Modules are installed)
• Maximum number of drives supported: 384 (480 with dense intermix drive
tray)
• Maximum cache memory supported: 128 GB (64 GB per controller)
Controller
Controller chassis Controller model Height
CBLM DW800-CBL DW-F800-CTLM 4U (174.3 mm)
Controller Model number Description
NAS DW-F800-NAS Optional component for file
storage configuration. NAS
modules only provide file
support.
Drive tray
Drive tray model
name
Supported drive
type
Number of drives
supported
Height
SFF drive tray • DW-F800-DBS
(power supply,
contains
BNST)
• DW-F800-
DBSC
2.5-inch SFF 24 2U (86.2 mm)
LFF drive tray • DW-F800-DBL
(power supply,
contains
BNST)
• DW-F800-
DBLC
3.5-inch LFF 12 2U (86.2 mm)
FMD tray • DW-F800-DBF 5.25-inch FMD 12 2U (86.2 mm)
Dense intermix
drive tray
• DW-F800-
DB60 (power
supply,
contains
BNST)
• DW-F800-
DB60C
3.5-inch LFF 60 4U (174.3 mm)
Related references
• Examples of supported VSP G400 configurations on page 23
20 Hitachi Virtual Storage Platform G400, G600 hardware overview
Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide
