Service processor description
The SVP provides four RJ-45 ports:
• Two ports connect to the storage system controllers (one port for each
controller).
• One port connects to the IP network of the user.
• One port connects to a user-supplied management console PC.
Note: This product is also designed for IT power distribution systems with
phase-to-phase voltage.
Three of the four RJ-45 ports (which connect to the controllers and the IP
network) are configured as a bridge. The SVP can be addressed using the
default IP address 192.168.0.15.
In the unlikely event you cannot connect to the SVP using the default IP
address, use the following emergency login: http://<default SVP IP
address>/dev/storage/<model number><system serial number>/
emergency.do. For example:
Storage system model number
Storage system serial number URL
8320004 456789 http://192.168.0.15/dev/
storage/8320004456789/
emergency.do
8340004 456789 http://192.168.0.15/dev/
storage/8340004456789/
emergency.do
8360004 456789 http://192.168.0.15/dev/
storage/8360004456789/
emergency.do
Users are responsible for adopting the appropriate security procedures with
the SVP, including:
• Applying Windows security patches.
• Turning on automatic Windows updates or using the manual Windows
update method.
• Installing antivirus software that has been tested and approved by Hitachi.
SVP front panel
The front panel of the physical SVP is equipped with LEDs, a reset button,
and a power button.
62 VSP service processor server
Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide
