OPERATOR'S STATION

1-156

 Aftertreatment Device Cover Mirror (8) (ZX345USLC-6 only)

 Adjust the mirror to the specified position.

 Adjust the mirror so that a range of at least 1 m from the

right side of the machine can be seen from the operator’s

seat.

View C

80 mm

MDD5-01-008

10°

MDD5-01-009

ZX345USLC-6
