OPERATOR'S STATION
1-6
Cab Features
ZX135US-6, 225US-6 class
1- Left Control Lever/Horn Switch
2- Left Travel Pedal
3- Left Travel Lever
4- Right Travel Lever
5- Right Travel Pedal
6- Right Control Lever/Power Boost Switch
7- Multi Function Monitor Panel
8- Switch Panel
9- Key Switch
10- Regeneration Switch
11- Operator's Seat
12- Cab Door Release Lever
13- Pilot Control Shut-Off Lever
14- Fuse Box
15- Cigar Lighter
16- Switch Panel (for Optional Equipments)
Glove Compartment (without Optional Equipment)
17- Glove Compartment (Hot and Cool Box)
18- Engine Stop Switch
19- 12 V Power Supply
20- USB Power Supply port
21- Screen Changeover Switch
1
2 3
7
9
10
11
18
12
13
8
4 5 6
MDCN-01-002
MDCN-01-004
MDAT-01-267
14
17
15
19
20
21
16
