MAINTENANCE

7-29

Optional Parts

Part No. Quantity

One Point Ripper

Tooth 4507888 1

Pin 4507890 1

Bushing Rubber 4507891 1

Ripper Bucket

Tooth 4507888 1

Pin 4507890 1

Bushing Rubber 4507891 1

Tooth 4383048 2

Lock Pin 4383069 2

Rock Bucket

Tooth 4400253 5

Lock Pin 4383465 5

Shroud 4435856 1

Shroud 4435857 1

Bolt J932780 6

Nut J951027 6

Washer 4085857 6

Reinforced Hoe Bucket HD

Type

Tooth 4512365 5

Lock Pin 4512366 5

Lock Rubber 4501625 5
