13-34
OPTIONAL ATTACHMENTS AND DEVICES
HYDRAULIC BREAKER, HYDRAULIC CRUSHER AND QUICK COUPLER
Part No. List (Fill attachment manufacturer's part Nos. in the blank spaces.)
Adapter Size Adapter Cap Plug Hose
Form / Size
PF-UNF
Male-Type
ZX135US-6 PF1-1-1/16UN 4456399 4222711 4222264
ZX225USLC-6, 345USLC-6 left
side piping
PF1X1-5/16UN 4214444 4222712 4222265
Form / Size
PF-PF30°
Female-Type
ZX135US-6 PF1-PF3/4 4129457 9718916 4222047
ZX225USLC-6, 345USLC-6 left
side piping
PF1XPF1 4042034 9718917 4168177
Form / Size
PF-PF30°
Male-Type
ZX135US-6 PF1-PF3/4 4456120 4222715 4222044
ZX225USLC-6, 345USLC-6 left
side piping
PF1XPF1 4456118 4222716 4222045
G
G
G G
G
G
G
G
UNF
UNF
UNF
UNF
37 °
30 °
30 °
30 °
30 °
30 °
30 °
37 °
37 °
