VISIBILITY MAP
S-48
: Operator’s eye point
: Masking area
A : 1m Rectangular Boundary (1mRB) : Mirror visibility
B : 12m Visibility Test Circle (VTC) : Camera visibility
: Standard Mirror(s)
: Masking on
1mRB / VTC
: Standard rear view camera
: Standard side view camera
MDAT-VM-093
B
A
mirror visibilitymirror visibility
camera
visibility
camera
visibility
Visibility Map
Image behind, image on right of machine
Monitor screen
MDC1-VM-040EN
MDAT-VM-094
B
A
mirror visibilitymirror visibility
camera
visibility
camera
visibility
Visibility Map
Image behind, image on right, image on left of machine
camera
visibility
Monitor screen
MDC1-VM-041EN
