4. LED status information
AC Cloud Control device has an external LED which uses to give the user a feedback to
communicate the status of the device.
4.1 LED status during Wi-Fi configuration
LED Color (s)
Behavior
Description
Blue
Blinking
Performing WPS connection (up to 2 min)
Magenta
Blink
WPS connection error
White
Blinking
Identifying AC Cloud Control Device
Green
Steady
Not configured
Green
Blinking
Checking device configuration parameter values (up to 2 min)
Red
Blinking
Connecting to access point and server (up to 2 min)
Yellow
Blinking
Downloading configuration. Wait (up to 2 min)
Red - Green
Alternate blinking
Error Connecting to Access point or router. Try to connect
again and make sure you write the correct password.
Yellow - Green
Alternate blinking
Server not reached. Check if there is Internet connectivity on
your Access Point or router.
4.2 LED status during IR configuration (Autolearning mode)
LED Color
Behavior
Description
White
Steady
Waiting customer pressing the On/Off button of the IR remote controller (up
to 20 seconds)
Green
Blinking
The IR remote controller has been linked as expected with the AC Cloud
Control device
Red
Blinking
The IR remote controller has NOT been linked as expected with the AC
Cloud Control device
Note: The autolearning can be performed just with Universal
AC Cloud Control devices.
!
