Hobart 210 MVP User Manual

. A complete Parts List is available at www.HobartWelders.com
OM-260 274 Page 11
SECTION 4 − SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number and rating information for this product is located on the back. Use rating label to determine input power requirements and/or rated
output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Unit Specifications For 230 VAC
Rated Welding
Output
Amperage
Range
Maximum Open-
Circuit Voltage
DC
Amperes Input at
Rated Load Output
230 V, 60 Hz,
Single-Phase
KVA KW
Weight
W/ Gun
Overall
Dimensions
150 A @ 23 Volts
DC, 30% Duty Cycle
25 − 210
34 24 5.54 4.72
79 lb
(36 kg)
Length: 19-1/2 in.
(495 mm)
Width: 10-5/8 in.
(273 mm)
Height: 12-3/8 in.
(314 mm)
Wire Type
And Diameter
Solid/
Stainless
Flux Cored
Aluminum Wire Feed Speed Range
.023 − .035 in.
(0.6 − 0.9 mm)
.030 − .045 in.
(0.8 − 1.2 mm)
.030 − .035 in.
(0.8 − 0.9 mm)
70 − 750 IPM (1.8 − 19.0 m/min) At No Load
40 − 680 IPM (1.0 − 17.3 m/min) Feeding Wire
4-3. Unit Specifications For 115 VAC
Rated Welding
Output
Amperage Range
Maximum
Open-Circuit
Voltage DC
Amperes Input at
Rated Load Out-
put 120 V, 60 Hz,
Single-Phase
KVA KW
Weight
W/ Gun
Overall
Dimensions
90 A @ 19
Volts DC, 20%
Duty Cycle
25 − 140
28 20 2.84 2.41
79 lb
(36 kg)
Length: 19-1/2 in.
(495 mm)
Width: 10-5/8 in.
(273 mm)
Height: 12-3/8 in.
(314 mm)
Wire Type
And Diameter
Solid/Stain-
less
Flux Cored Aluminum
Wire Feed Speed Range
.023 - .035 in.
(0.6 - 0.9
mm)
.030 - .035 in.
(0.8 - 0.9
mm)
.030 in.
(0.8 mm)
60 − 740 IPM (1.5 − 18.8 m/min) At No Load
40 − 600 IPM (1.0 − 15.2 m/min) Feeding Wire

Hobart 210 MVP Specifications

General

Weldable Materials	Steel, Stainless Steel, Aluminum
Processes	MIG (GMAW), Flux-Cored (FCAW)
Input Frequency	60 Hz
Amperage Output	140A
Spool Size Capacity	4 in / 8 in
Welding Amperage Range	25-140A (120V), 25-210A (240V)
Input Phase	Single Phase
Wire Size	0.023-0.035 in (0.6-0.9 mm)
Input Voltage	115V / 230V
