Hobart 210 MVP User Manual

. A complete Parts List is available at www.HobartWelders.com
OM-260 274 Page 19
5-11. Connecting Input Power
! Do Not modify or rewire receptacle
connection.
! Do Not cut off power cord connector
and rewire. The power cord
connector and plugs will work with
standard NEMA receptacles.
Modifying power cord, connector,
and plugs will void product
warranty.
! Special installation may be required
where gasoline or volatile liquids
are present − see NEC Article 511 or
CEC Section 20.
Supply correct input power (see Section
4-1).
For 115 VAC input power, a 20 ampere
individual branch circuit protected by
time-delay fuses or circuit breaker is
required, see Section 5-13. For 230 VAC
input power, see Section 5-12.
1 Power Cord Connector
2 Plug − NEMA Type 5-15P
3 Receptacle − NEMA Type 5-15R
(Customer Supplied)
4 Plug − NEMA Type 5-20P (Optional)
5 Receptacle NEMA Type 5-20R
(Customer Supplied)
6 Plug − NEMA Type 6-50P
7 Receptacle − NEMA Type 6-50R
(Customer Supplied)
Select plug for power supply receptacle
available at site. Install plug onto power
cord adapter. As threaded collar is
tightened, push plug onto adapter until
collar is completely tight.
Connect plug to receptacle.
250 332-B
3
5
7
2
4
6
1
Align arrows before threading together

Hobart 210 MVP Specifications

General

Weldable Materials	Steel, Stainless Steel, Aluminum
Processes	MIG (GMAW), Flux-Cored (FCAW)
Input Frequency	60 Hz
Amperage Output	140A
Spool Size Capacity	4 in / 8 in
Welding Amperage Range	25-140A (120V), 25-210A (240V)
Input Phase	Single Phase
Wire Size	0.023-0.035 in (0.6-0.9 mm)
Input Voltage	115V / 230V
