NOMENCLATURE UNITS
FIGURE HOBART EFF PER
ITEM NO. PART NO. 1234567 ASSY
2- 489591 YOKE, LIFTING ASSY. (For NHA See Fig. 1) AC 1
180364 YOKE, LIFTING ASSY. (For NHA See Fig. 1) BDE 1
1 489582 . . YOKE LIFTING 1
2 406392-1 . . TRANSFORMER, CONTROL, V97520,
NO. 18608001 AC 1
406392-2 . . TRANSFORMER, CONTROL, V97520,
NO. 18608001 BDE 1
3 W-11166-11 . . FUSE, FAST BLOW, AGC, V71400,
NO. AGC-1/2 1
4 81B-1061 . . LABEL, WARNING, ELECTRIC SHOCK 1
5 406484 . . LABEL, FUSE, R-400S, 0.5 AMP, 250V 1
6 400663 . . CONTACTOR, V23826, NO. 42EE35AF-263 1
7 W-11114-5 . . SCREW, 1/4-20 X 1, RD HD, MH.ST 2
8 W-11263-4 . . WASHER, LK, IET, Y4 3
9 50MS-732-0 . . NUT, 1/4-20, HEX, KEPS, ST. 5
10 405362-2 . . BUSHING, SNAP 1
11 487815 . . PANEL, MTG. PC BOARD 1
* 12 180294 . . BOARD, PC AB 1
180294A . . BOARD, PC, POWER SUPPLY CDE 1
13 405915-1 . . SPACER, PC BOARD, VO2768,
NO. 217-200-502-06-0101 6
14 487979 . . SPACER, PANEL, MOUNTING, PC 2
15 W-11242-5 . . WASHER, ST. 1/4, FL. 4
16 487897 . . BAR, BUS CONTACTOR 1
17 405042-1 . . CONTACTOR, 28V, V50603, NO. HB309AE 1
18 487898A . . BRACKET, CONTACTORS 1
19 82B-1023 . . LABEL, WARNING, TRANSFORMER-RECTIFIER 1
20 489609 . . PANEL, MOUNTING, P-C 1
* Not Illustrated
March 17/93 Revised 4-3
Page 7
OM-2010
