NOMENCLATURE UNITS
FIGURE HOBART EFF PER
ITEM NO. PART NO. 1234567 ASSY
3- 489700 RECTIFIER, OUTPUT ASSEMBLY,
(For NHA See Fig. 1) REF
1 367634A-3 . . SUPPRESSOR, SURGE ASSY 2
2 200880 . . HEAT SINK, RECTIFIER 1
3 404044-3 . . THERMOSTAT, OVERLOAD, 02907, V14604,
NO. 2450-82-175 1
4 406990 . . RECTIFIER, SILICON, CONT. V81483, NO. 550PB40 6
5 280023 . . SHUNT, 1200-AMP, 50 MV 1
6 W-11097-6 . . SCREW, 3/8-16 X 1-3/4, HHC. ST 1
7 W-11242-10 . . WASHER, FL. ST. 3/8 2
8 W-11254-6 . . WASHER, LK, ST. 3/8 1
9 W-11278-5 . . NUT, 3/8-16, HEX, FULL, ST. 1
10 369641 . . INSULATOR, MTG, RECTIFIER 2
11 W-10931-3 . . DIODE, SILICON, POS. BASE, V05277,
NO. R6100328 1
12 W-11242-6 . . WASHER, FL. 5/16 ST. 1
13 W-11254-5 . . WASHER, LK. 5/16 ST. 1
14 W-11278-6 . . NUT, 5/16-18, HEX FULL ST. 1
15 201014 . . HEAT SINK, SCR 6
16 405140-2 . . CLAMP, MOUNTING 6
17 404044-6 . THERMOSTAT, FAN TURN-ON 1
* Not Illustrated
OM-2010
December 16/91 Revised 4-3
Page 9
