Instruments and Controls 55
Tachometer
Shows engine speed in thousands
of revolutions per minute (RPM).
Drive at a low engine speed/range
for each gear, as much as possible.
The pointer may shake slightly after
the engine is turned off. This is not
a malfunction but normal operation
to ensure correct pointer position.
{
Warning
Do not allow the needle to remain
in the warning/red zone.
Fuel Gauge
Shows the level of fuel in the tank
(E = empty, F = full).
Movement of the fuel within the fuel
tank may cause the fuel gauge
indicator to move when braking,
accelerating or turning.
{
Danger
Before refuelling, stop the vehicle
and switch the engine off.
Control Indicators
The vehicle may have the following
indicators.
Indicators illuminate for a short time
when the ignition is turned on to
show that the light is working.
Red: danger, important reminder
Yellow: warning, information, fault
Green: confirmation of activation
Blue: confirmation of activation
Note
Depending on vehicle variant, the
instrument cluster appearance may
differ.
