Holtek HT46R47 - Page 153

18-pin DIP (300mil) Outline Dimensions
Symbol
Dimensions in mil
Min. Nom. Max.
A 895
¾
915
B 240
¾
260
C 125
¾
135
D 125
¾
145
E16
¾
20
F50
¾
70
G
¾
100
¾
H 295
¾
315
I 335
¾
375
a 0°¾15°
144
A/D Type MCU
1 8
1
1 0
9
a
A
B
C
D
E
F
G
H
I
