HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
• TM1DL Register – 10-bit ETM
Bit 7 6 5 4 3 2 1 0
Name
D7 D6 D5 D4 D3 D2 D1 D0
R/W R R R R R R R R
POR 0 0 0 0 0 0 0 0
Bit7~0 TM1DL:TM1CounterLowByteRegisterbit7~bit0
TM110-bitCounterbit7~bit0
• TM1DH Register – 10-bit ETM
Bit 7 6 5 4 3 2 1 0
Name — — — — — — D9 D8
R/W — — — — — — R R
POR — — — — — — 0 0
Bit7~2 Unimplemented,readas“0”
Bit1~0 TM1DH:TM1CounterHighByteRegisterbit1~bit0
TM110-bitCounterbit9~bit8
• TM1AL Register – 10-bit ETM
Bit 7 6 5 4 3 2 1 0
Name
D7 D6 D5 D4 D3 D2 D1 D0
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7~0 TM1AL:TM1CCRALowByteRegisterbit7~bit0
TM110-bitCCRAbit7~bit0
• TM1AH Register – 10-bit ETM
Bit 7 6 5 4 3 2 1 0
Name — — — — — — D9 D8
R/W — — — — — — R/W R/W
POR — — — — — — 0 0
Bit7~2 Unimplemented,readas“0”
Bit1~0 TM1AH:TM1CCRAHighByteRegisterbit1~bit0
TM110-bitCCRAbit9~bit8
• TM1BL Register – 10-bit ETM
Bit 7 6 5 4 3 2 1 0
Name
D7 D6 D5 D4 D3 D2 D1 D0
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7~0 TM1BL:TM1CCRBLowByteRegisterbit7~bit0
TM110-bitCCRBbit7~bit0
