• SIMC0 Register
Bit 7 6 5 4 3 2 1 0
Name SIM2
SIM1 SIM0 PCKEN PCKP1 PCKP0 SIMEN —
R/W R/W R/W R/W R/W R/W R/W R/W —
POR
1 1 1 0 0 0 0 —
Bit7~5 SIM2, SIM1, SIM0:SIMOperatingModeControl
000:SPImastermode;SPIclockisf
SYS
/4
001:SPImastermode;SPIclockisf
SYS
/16
010:SPImastermode;SPIclockisf
SYS
/64
011:SPImastermode;SPIclockisf
TBC
100:SPImastermode;SPIclockisTM0CCRPmatchfrequency/2
101:SPIslavemode
110:I
2
Cslavemode
111:Unusedmode
ThesebitssetuptheoveralloperatingmodeoftheSIMfunction.Aswellasselecting
iftheI
2
CorSPIfunction,theyareusedtocontroltheSPIMaster/Slaveselectionand
theSPIMasterclockfrequency.TheSPIclockisafunctionofthesystemclockbut
canalsobechosentobesourcedfromtheTM0.IftheSPISlaveModeisselectedthen
theclockwillbesuppliedbyanexternalMasterdevice.
Bit4 PCKEN:PCKOutputPinControl
0:Disable
1:Enable
Bit3~2 PCKP1, PCKP0:SelectPCKoutputpinfrequency
00:f
SYS
01:f
SYS
/4
10:f
SYS
/8
11:TM0CCRPmatchfrequency/2
Bit1 SIMEN:SIMControl
0:Disable
1:Enable
Thebitistheoverallon/offcontrolfortheSIMinterface.WhentheSIMENbitis
clearedtozerotodisabletheSIMinterface,theSDI,SDO,SCKandSCS,orSDA
andSCLlineswillbeinaoatingconditionandtheSIMoperatingcurrentwillbe
reducedtoaminimumvalue.WhenthebitishightheSIMinterfaceisenabled.The
SIMcongurationoptionmusthaverstenabledtheSIMinterfaceforthisbittobe
effective.IftheSIMisconguredtooperateasanSPIinterfaceviaSIM2~SIM0bits,
thecontentsoftheSPIcontrolregisterswillremainattheprevioussettingswhenthe
SIMENbitchangesfromlowtohighandshouldthereforeberstinitialisedbythe
applicationprogram.IftheSIMisconguredtooperateasanI
2
Cinterfaceviathe
SIM2~SIM0bitsandtheSIMENbitchangesfromlowtohigh,thecontentsoftheI
2
C
controlbitssuchasHTXandTXAKwillremainattheprevioussettingsandshould
thereforebefirstinitialisedbytheapplicationprogramwhiletherelevantI
2
Cflags
suchasHCF,HAAS,HBB,SRWandRXAKwillbesettotheirdefaultstates.
Bit0 Unimplemented,readas“0”
