Holtek HT66F30 User Manual

Rev. 2.50 262 June 22, 2017 Rev. 2.50 263 June 22, 2017
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
Mnemonic Description Cycles Flag Affected
Data Move
MOV A,[m] Move Data Memory to ACC 1 None
MOV [m],A Move ACC to Data Memory 1
Note
None
MOV A,x Move immediate data to ACC 1 None
Bit Operation
CLR [m].i Clear bit of Data Memory
1
Note
None
SET [m].i Set bit of Data Memory
1
Note
None
Branch Operation
JMP addr Jump unconditionally 2 None
SZ [m] Skip if Data Memory is zero
1
Note
None
SZA [m] Skip if Data Memory is zero with data movement to ACC
1
Note
None
SZ [m].i Skip if bit i of Data Memory is zero
1
Note
None
SNZ [m].i Skip if bit i of Data Memory is not zero
1
Note
None
SIZ [m] Skip if increment Data Memory is zero
1
Note
None
SDZ [m] Skip if decrement Data Memory is zero
1
Note
None
SIZA [m]
Skip if increment Data Memory is zero with result in ACC 1
Note
None
SDZA [m]
Skip if decrement Data Memory is zero with result in ACC 1
Note
None
CALL addr
Subroutine call 2 None
RET
Return from subroutine 2 None
RET A,x Return from subroutine and load immediate data to ACC 2 None
RETI
Return from interrupt 2 None
Table Read Operation
TABRD [m] Read table (specic page) to TBLH and Data Memory 2
Note
None
TABRDC [m]
Read table (current page) to TBLH and Data Memory 2
Note
None
TABRDL [m] Read table (last page) to TBLH and Data Memory 2
Note
None
Miscellaneous
NOP No operation
1 None
CLR [m] Clear Data Memory
1
Note
None
SET [m] Set Data Memory
1
Note
None
CLR WDT Clear Watchdog Timer
1 TO, PDF
CLR WDT1 Pre-clear Watchdog Timer 1 TO, PDF
CLR WDT2 Pre-clear Watchdog Timer 1 TO, PDF
SWAP [m] Swap nibbles of Data Memory 1
Note
None
SWAPA [m]
Swap nibbles of Data Memory with result in ACC 1 None
HALT Enter power down mode
1 TO, PDF
Note:1.Forskipinstructions,iftheresultofthecomparisoninvolvesaskipthentwocyclesarerequired,ifno
skiptakesplaceonlyonecycleisrequired.
2.AnyinstructionwhichchangesthecontentsofthePCLwillalsorequire2cyclesforexecution.
3.Forthe“CLRWDT1”and“CLRWDT2”instructionstheTOandPDFflagsmaybeaffectedbythe
executionstatus.TheTOandPDFflagsareclearedafterboth“CLRWDT1”and“CLRWDT2”
instructionsareconsecutivelyexecuted.OtherwisetheTOandPDFagsremainunchanged.
