HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
PRM2 Register
• HT66F50/HT66F60
Bit 7 6 5 4 3 2 1 0
Name
TP31PS TP30PS TP21PS TP20PS TP1B2PS TP1APS TP01PS TP00PS
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7 TP31PS:TP3_1PinRemappingControl
0:TP3_1onPD0
1:TP3_1onPE3
Bit6 TP30PS:TP3_0PinRemappingControl
0:TP3_0onPD3
1:TP3_0onPE5
Bit5 TP21PS:TP2_1PinRemappingControl
0:TP2_1onPC4
1:TP2_1onPD4
Bit4 TP20PS:TP2_0PinRemappingControl
0:TP2_0onPC3
1:TP2_0onPD1
Bit3 TP1B2PS:TP1B_2PinRemappingControl
0:TP1B_2onPC5
1:TP1B_2onPE4
Bit2 TP1APS:TP1APinRemappingControl
0:TP1AonPA1
1:TP1AonPC7
Bit1 TP01PS:TP0_1PinRemappingControl
0:TP0_1onPC5
1:TP0_1onPD5
Bit0 TP00PS:TP0_0PinRemappingControl
0:TP0_0onPA0
1:TP0_0onPC6
