14.1 Setting the channels on EMP 800.00 v7
(Electronic coin tester)
YourUNOhasbeenequippedwithanelectronicmulticoinac-
ceptor(EMP).Itcanrecogniseupto6di󰀨erenttypesofcoins.
Whenacoinhasbeeninserted,itonlyrealisesthatacoinhas
been inserted but it does not which value the coin should have.
Theevaluationishelpedbythechannelvalueprogram.
Therecognitionandevaluationrunsasfollowing…
...in the electronic multiple coin acceptor (EMP) … in UNO
1. coin was thrown in 2. coin is assigned the
channel in the EMP
3."Exitchannel"ofEMPisas-
signedthe"Entrance"ofUNO
4.the"entrance"ofUNOis
assigned (by the factory
orindividually)theprograms
value
EUR0,50 1 E1 e.g.0,50EUR(bythefactory)
EUR1,00 2 E2 e.g.1,00EUR(bythefactory)
EUR2,00 3 E3 e.g.2,00EUR(bythefactory)
EUR0,20 4 E4 e.g.0,20EUR(bythefactory)
- 5 E5 e. g. free (by the factory)
Holtkampstandardtoken 6 E6 e.g.3,50EUR(bythefactory)
Theallocationofthechannelstothethrownincoinscanbein-
ferredfromthestickeronthesidecoveroftheelectronicmultiple
coinacceptor.Thereisthepossibilityofclosingindividualchan-
nels.Thusthecoinacceptanceisblocked.
1 - 8 9 - 16
