Holtkamp Electronics UNO 7600XL engl. techn. Stand 04.2016 4050_04.2016 V09.2019
- 22 -
Display shows Factory setting Description
Currency EUR Thecurrencyadjustmento󰀨ersthepossibility,underthecurrencyabbreviation
EUR;neutral(noabbreviation)PLN;SKr;Kn;GBP;DkrorKr.Thecurrency
abbreviation appears on the display.
Paymenttype XX Underthemenuitemyoucanndfollowingpaymenttypes:normal,several
Happy Hour types, discount system, three di󰀨erent FairPlay payment types,
orskintyperecognising,whichcanbechosenbyRESET-andPLUSbuttons.
Paymenttype normal Bypayment“normal”youhavethepossibilitytoenteronepriceandonetime.
Thecorrelation of the channels to the thrown in coins you can
alsoseeonthelabelonthecoverfromthecointester.
Itispossible,toblockedseveralcoins.Therebythecoinaccep-
tation is refused.
9 10 11 12 13 14 15 16
2,0EURO
wide
yes
2,0EURO
middle
yes
0,5EURO
wide
yes
0,5EURO
narrow
yes
1,0EURO
narrow
yes
Teach
function
no
EURO
yes
2,0EURO
narrow
yes
1 2 3 4 5 6 7 8
Token
standard
no
0,2EURO
wide
no
0,2EURO
middle
no
Token
contour
no
0,5EURO
middle
yes
1,0EURO
wide
yes
1,0EURO
middle
yes
Activating
coin accep-
tance
yes
InthebasicadjustmentoftheEMPthechannelsfor0,2Euroand
thetokensareclosed.
Notes for the electronic multi coin acceptor
YourUNOisequippedwithanelectronicmultiplecoinacceptor.
Please consider the following noticing:
● Wellworn,dirty,damaged,falseandforeigncurrencycoins
will not be accepted.
● Ifanapparentlygoodcoinisnotaccepted,pleaseusean-
other coin.
● Neverinsertmorethanonecoinatthesametime.
● Pressthecoinreturnbuttontoreleasejammedcoins.
● Whennocoinsareaccepted,ashort(5seconds)breakof
the power input often helps.
● Usetheelectroniccointesteronlybetweentemperaturesof
 0ºC–50ºCandatrelativehumiditiesof20%-85%
Youcanenableanddisableindividual cointypeswiththehelp
ofcertainDIPswitchcombinations.Thereare16DIPswitches,
whicharenumberedaftertheupperimaging.
● Strongtemperaturesuctuationsandmagneticeldscould
 a󰀨ecttheacceptancebehaviourofthecoinacceptor.
● Theremovingorinstallingofanelectronicmulticoinacceptor
 maybecarriedoutonlybypoweroutput.
Forsafetyreasonsamodicationofthefactorysetting
channel values are only possible, if DIP switch no. 1
and 2 on the XL-PCB adjusted to „on“ (upwards) at
 rstorbyusingofthecongurationcardtype83.
After changing the channel values you must set the
 DIPswitches1and2backto„o󰀨“(down).

