HOLUX GR-230 Bluetooth GPS Receiver Manual
7
4.6. Output and Interface
 Output
I. Output protocol
Baud Rate： 38400 bps
Data bit： 8
Parity： No
Stop bit： 1
II. Format. NMEA0183 V2.2： GPGGA (1time/1 sec), GPGSA (1 time/1 sec.),
GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), (GLL, VTG or SiRF binary
format for optional).
III. Datum： WGS84.
 Input/ Output Interface:
I. Compatible Bluetooth Serial Port Profile (SPP), Version1.1 and class 2(up
to 10 meter range).
II. In/Out Port. GPS signal (Out)/Command(In) with CMOS/TTL Level。Mini
USB Type B Connector and Cable option：
(a) GR230-A1(RS232 data cable)
(b) GR230-A2 (USB data cable)
(c) GR230-A3 (Mini USB port to PS2 port ).
 External Antenna interface:
3.0V input MCX type active antenna connector。
4.7. Physical
 Size： 72 × 55 × 21 mm。
 Weight： < 75 g 。
 Operating Temperature： -10 to + 60
 Storage Temperature： -20 to + 85
 Operating humidity： 5% to 95% No condensing。
4.8. Other Functions
 Bluetooth frequency: 2.4 ~2.48GHZ。
 Bluetooth Input Sensitivity: -80dbm。
 Low sensitivity of receiving satellite signal
： -175dBW。
 LED Functions
： Indicate Bluetoothh status, GPS status, Battery Status and
Battery charging status。
