I NSTALLATI ON
HOLZMANN Maschinen Austria www.holzmann-maschinen.at
Seit e 3 1
Metalldrehmaschine / metal turning lathe ED 750 FDQ
1 4 I NSTALLATI ON
1 4 .1 Transportation
The machine is transported in a special wooden case (or with foot stands separately packed in
carton), being fixed to the base of the case or slide by suitable bolts. Some of the accessories are
mounted on the lathe well fixed and the other packed in a separate box or directly fixed on the
case base.
The places where the ropes or chains have to be passed during handling of the packed machine
are marked on the packing. Be aware of the heavy side while you are handling the machine with
forklift.
1 4 .2 Unpacking
After the machine had been unpacked, check carefully its general condition, as well as the avail-
ability and condition of all the accessories, shown in the packing list.
1 4 .3 Handling
Unpacked machine shall be handled only by the help of a suitable crane. Before passing the ropes
over the lathe, pull out the tailstock and carriage and fix them in the rear hand position so that
when lifting the machine you will obtain required balancing. When handling the machine never
strike or hit it sharply because this may affect the machine accuracy—irrespective of whether
there are or not may visible defects.
Since the paint on some part of the machine may be damaged during handling, place protective
pads of fabrics or other suitable material on the respective places.
1 4 .4 Preparation
Before mounting the machine on the predetermined place, clean it carefully from the protective
oil. Respective machine surface shall be washed by the help of pure naphtha or benzine.
This protective oil shall not be removed by hard objects or solvent that may damage the metal
surface or paint of the machine. Well-cleaned surfaces are dried by the help of dry threads and
covered with pure machine oil. Remove the end gear cover. Clean all components of the end
gear assembly and coat all gears with heavy, non-slinging grease.
1 4 .5 Connection t o the electronical supply source
Check whether the data on the el. panel scheme (voltage and frequency of the supply source)
correspond to the available.
Make sure the lathe in properly grounded.
Connection of the lathe and all other electrical w ork m ay only be carried out by an au-
thorized electrician!
Failure to com ply m ay ca use serious injury and dam age to the m achinery and property!
