ERSATZTEI LE / SPARE PARTS
HOLZMANN Maschinen Austria  www.holzmann-maschinen.at
Seit e 5 3
Metalldrehmaschine / metal turning lathe ED 750 FDQ
P1 0 8
1----------------GB10801-------------------------------------------------------BOLT M10x1x10
2----------------P10801------------------------------------------------------------------------PLUG
3----------------GB10802----------------------------------------------------BEARING 1000802
4----------------P10802------------------------------------------------------------------------GEAR
5----------------P10803-----------------------------------------------------------------------SHAFT
6----------------GB10803---------------------------------------------------------------KEY A4x55
7----------------P10804------------------------------------------------------------------------GEAR
8----------------P10805-------------------------------------------------------------------GEAR BOX
9----------------P10806-----------------------------------------------------------------------COVER
10---------------GB10804---------------------------------------------------CAP SCREW M5x20
11---------------GB10805---------------------------------------------------CAP SCREW M6x90
12---------------GB10806-----------------------------------------------------------------PIN 3x20
13---------------GB10807----------------------------------------------------CAP SCREW M8x90
14---------------P10807-----------------------------------------------------------------------PLATE
15---------------GB10808----------------------------------------------------------- -SCREW M3X6
16---------------GB10809---------------------------------------------------SIGHT GLASS 20mm
17---------------P10808-------------------------------------------------------------SPACING RING
18---------------GB10810------------------------------------------------------------BEARING 202
19---------------P10809------------------------------------------------------------------GEAR 25T
20---------------GB10811-----------------------------------------------------------------KEY A4x8
21---------------P10810-----------------------------------------------------------------------SHAFT
22---------------GB10812------------------------------------------------------------BEARING 103
23---------------P10811------------------------------------------------------------PAPER WASHER
24---------------P10812---------------------------------------------------------------------FLANGE
25---------------GB10813-----------------------------------------------------OIL SEAL 17x30x10
26---------------GB10814-----------------------------------------------------CAP SCREW M5x20
27---------------GB10815-----------------------------------------------------OIL SEAL 15x30x10
28---------------P10813---------------------------------------------------------------------FLANGE
29---------------P10814----------------------------------------------------------------GEAR SHAFT
30---------------GB10816------------------------------------------EXT RETAINING RING 12mm
31---------------P10815---------------------------------------------------------------SHIFT LEVER
32---------------GB10817------------------------------------------------------------O-RING 9x1.8
33---------------P10816---------------------------------------------------------------------HANDLE
34---------------GB10818---------------------------------------------------------------STEEL BALL
35---------------P10817---------------------------------------------------------------------SPRING
36---------------GB10819------------------------------------------------------------SCREW M6x6
37---------------P10818------------------------------------------------------------------------FORK
38---------------GB10820-----------------------------------------EXT RETAINING RING 10mm
39---------------GB10821-----------------------------------------------------------------KEY B4x6
40---------------P10819-----------------------------------------------------------INDICATOR DISK
41---------------GB10822------------------------------------------------------------SCREW M4x8
