ERSATZTEI LE / SPARE PARTS
HOLZMANN Maschinen Austria  www.holzmann-maschinen.at
Seit e 5 6
Metalldrehmaschine / metal turning lathe ED 750 FDQ
P1 0 1 0
1..……..….GB101001……………………………..………………………………KEY A4x14
2..……..….GB101002……………………………..……………………………….RIVET 2x4
3..……..….P101001………………………………..……………………………………..PLATE
4..……..….P101002………………………………...…………………………………..FLANGE
5..……..….GB101003………………………………...…………………CAP SCREW M4x10
6..…..…….P101003…………………………………….…………………GRADUATED DIAL
7..…..…….P101004……………………………………..……………………………..CURSOR
8..…..…….P101005…………………………………….……………………….HAND WHEEL
9..…..…….GB101004…………………………………………………FLAT WASHER 10mm
10..……….GB101005…………………………………………………………HEX NUT M10
11..……….GB101006…………………………………………………………HEX NUT M10
12..……….P101006…………………………………………………………HANDLE SCREW
13..……….P101007……………………………………………………………………HANDLE
14..……….GB101007…………………………………………………...……………PIN 4x20
15..……….P101008………………………………………………………………….…FLANGE
16..……….P101009……………...…………………………………………………GEAR 70T
17..……….P101010………………….…………………………………………SPACING RING
18..……….GB101008…………………………………………………………OIL PORT 8mm
19..……….P101011………………………………………………………………GEAR SHAFT
20..……….P101012………………………………………………………………GEAR SHAFT
21..……….P101013…………………………………...………………………………BUSHING
22..……….GB101009…………………………………..………………………SCREW M4x6
23..……….GB101010…………………………………...………………CAP SCREW M5x12
24..……….GB101011…………………………………….…………BIG FLAT WASHER 5mm
25..……….P101014………………………………………………...………………GEAR 30T
26..……….GB101012………………...………………………………………………PIN 3x18
27..……….P101015…………………….………………………………………SPACING RING
28..……….P101016……………………………..……………………………………BUSHING
29--------P101017……………………………………………………………………GEAR
30..……….GB101013………………………………………..……………………KEY C4x10
31..……….GB101014…………………………………………..…………………KEY A5x30
32..……….P101018………………………………………………………………………SHAFT
33..……….GB101015…………………………………………………………OIL PORT 6mm
34..……….GB101016……………………..……………………………………SCREW M6x6
35..……….P101019……………………......……………………………………………SPRING
36..……….GB101017………………….…………………………………STEEL BALL 5mm
37..……….P101020………………………………………………………………………PLATE
38..……….GB101018……………………………………..…………………………PIN 3x12
39..……….P101021…………………………………….…………………LOCATING BLOCK
40..……….P101022………………………………………………………………………SHAFT
41..……….P101023………………………………………………………………..………FORK
42..……….GB101019………………….………………………………………………PIN 3x26
43..……….P101024…………………………...………………………………………BUSHING
44..……….GB101020…………...……………………………………………………PIN 3x35
45..……….GB101021……...……………………………………………CAP SCREW M4x35
46..……….P101025…………………………………………………………………-BRACKET
