Homelite ZIP START User Manual

10
1 •UP 06959 HANDLE-Anti-Vibe 1
2 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
3 UP 06523 SCREW-Cap Hex Hd. 1
4 • UP 05136 DRIVESHAFT ASSY. (Upper) 1
5 UP 06960 FLEXSHAFT 1
6 • UP 03839 COUPLER ASSEMBLY 1
7 UP 05137 KNOB 1
8 • UP 03851 DRIVESHAFT HOUSING (Lower) 1
9 UP 04541 SHAFT-Flex 1
10 UP 04352 DECAL-Warning 1
11 UP 04137 CLAMP 1
12 UP 04256 SCREW-Sems Hex (10-24 X 3/8") 1
13 •UP 06710 DEFLECTOR & BLADE KIT (55 Deg.) 1
14 UP 06523 SCREW-Cap Hex Hd. (10-24 X 2") 1
15 UP 03415 WASHER-Flat (1/4") 1
16 UP 03409 WASHER-Lock (1/4") 1
17 UP 04262 NUT-Wing, Washer Faced (1/4-20) 1
18 •UP 04119 BLADE-Cut-Off 1
19 UP 04159 SCREW-Mech. Hex Hd. (10-24 X 7/8") 2
20 UP 04150 NUT-Hex (10-24) 2
No. Part No. Description Qty.
SHAFT - SPOOL & STRING - GRASS DEFLECTOR
3
1
2
14
13
10
8
18
15
11
20
12
19
9
17
16
4
6
5
7
21 •DA 03001 A STRINGHEAD-Complete (.080") 1
22 UP 06567 HOUSING & EYELET (Dual Line) 1
23 • UP 00145 SPOOL & STRING (.080") 1
24 UP 06526 SPRING-Compression 1
25 UP 04273 RETAINER-Spool (R.H. Thread, Black) 1
No. Part No. Description Qty.
Warranty Flat Rate
Job Description Time/Hr.
2 ....... 5-25 ......... .6-2.8
12 ....... 15-25 ......... 1.7-2.8
17 ....... 5-25 ......... .6-2.8
20 ....... 30-40 ......... 3.4-4.5
FM10 .. Stringhead Assy. ......................... .2
FN12 ... Driveshaft (Upper) ...................... .3
FN13 ... Driveshaft Housing ..................... .3
FN16 ... Deflector ...................................... .2
CD98 .. Coupler-Shaft .............................. .3
Torque Specs
Item Required
No. In/Lbs Nm Loctite
23
25
22
24
21
Versa Tool .................. (UT20816, UT20838)
6/18/2001

Homelite ZIP START Specifications

General

Brand	Homelite
Model	ZIP START
Category	Trimmer
Language	English
