132
MAINTENANCE
Mechanical wire type
DBW type
Fuse No. Rating Component(s) or Circuit(s) Protected
1 150 A ACG, Battery
430 A
STARTER SOLENOID, AND RELAYS IN JUNCTION BOX
5 10 A Power tilt relay, Warning buzzer, Indicator, Meter
8 10 A Fuel pump (High pressure side)
9 15 A Injector, ECU
10 10 A DLC, Fuel pump (Low pressure side)
11 15 A PTC
Fuse No. Rating Component(s) or Circuit(s) Protected
1 150 A ACG, Battery
430 A
STARTER SOLENOID, AND RELAYS IN JUNCTION BOX
5 7.5 A REMOTE CONTROL SYSTEM
6 30 A SHIFT ACTUATOR
7 15 A THROTTLE BODY
8 10 A Fuel pump (High pressure side)
9 15 A Injector, ECU
10 10 A DLC, Fuel pump (Low pressure side)
11 15 A PTC
