CONTROLS AND FEATURES
The ACG indicator turns on and the
buzzer sounds when the charging
system is faulty.
ACG Indicator/Buzzer
(R1 type)
(RED)
(RED)
ACG
INDICATOR
BUZZER
(R2, R3 type)
ACG
INDICATOR
BUZZER
Display assy
ACG INDICATOR
(RED)
Oil Pressure Indicator/Buzzer
(R1 type)
(GREEN)
OIL PRESSURE
INDICATOR
(R2, R3 type)
BUZZER
OIL PRESSURE
INDICATOR
(GREEN)
BUZZER
