104
Vertical transport
TRANSPORTING
WASHER
WASHER
BOLT
NUT
STERN BRACKET
MOTOR STAND
Transport the outboard motor either
vertically or horizontally as follows
with the steering handle raised.
Attach the stern brackets to a
motor stand and mount the
outboard motor to the brackets.
Transport the outboard motor with
the tiller handle raised.
1. 2.
