Honda BF8D - Page 42

−
−−
29 39 N·m
(3.0 4.0 kgf·m , 22 29 lbf·ft)
Install the outboard motor
securely. Loosely mounted
outboard motor can result in
accidental loss of the outboard
motor and damage and injury to
the equipment and personnel.
While operating the boat,
check the tightness of the
clamp screws occasionally.
Tie a rope through the hole in
the stern bracket and secure
the other end of the rope to
the boat. This will prevent
accidental loss of the
outboard motor.
42
INSTALLATION
BOLT
MOUNTING HOLE
TRANSOM
BOARD
LOCK NUT
WASHER
WASHER
The standard torque is given just as a
guideline. Torque of the nut can be
different according to the material of
the boat. Consult with an authorized
Honda outboard motor dealer.
Apply the silicone sealant (Three
Bond 1216 or equivalent) to the
outboard motor mounting holes.
Set the outboard motor on the boat
and secure with the bolts, washers,
and lock nuts.
Standard torque:
2.
3.
