5.
Remove the rear ax
le
shaft,
side
collars
and rear wheel.
....
Support the brake
ca
liper assembly
so
that
it doesn't hang from the brake
hose.
Do
not
twist
the brake hose.
....
Avoid getting grease, oil, or dirt on
the disc
or
pad surfaces.
....
Do
not
push the brake pedal while the
brake
caliper
is
removed.
Installation
1.
To
install the rear wheel,
reverse
the
removal procedure.
....
Take care
to
prevent the brake caliper
from scratching the wheel during
installation.
Tire Puncture
~
Removing Wheels
lmim
When
installing
the
brake
caliper
into
position,
carefully
fit
the
brake
disc
between
the
pads
to
avoid
scratching
them.
2. Make sure
that
the lug on the brake
ca
liper bracket is positioned
in
the slot on
the swingarm .
Slo
t~
11
,e_
I
Lug
Sw
ingarm
•
continued 89
