Removing & Installing Body Components
Seat
Front stay
Front prong
Rear prongs
Rear stay
Seat lock
Ignition
key
Lock
lever
Pull
Seat
❙
Removal
1. Insert the ignition key into the seat lock
and turn it clockwise.
2. Pull the seat lock lever downward to
unlock the seat.
3. Pull the seat back and up.
❙
Installation
1. Insert the front prong into the front stay
and the rear prongs into the rear stays on
the frame.
2. Push forward and then down on the rear
of the seat.
a
Make sure that the seat is locked
securely in position to pull it up lightly.
a
The seat locks automatically when
closed. Take care not to lock your key
under the seat.
