Maintenance
Removing & Installing Body Components
a
Side Covers
Side Covers
The right side cover must be removed to
access the coolant reserve tank.
The left side cover must be removed for fuse
maintenance.
The right and left side covers can be
removed in the same manner.
❙
Removal
1. Remove the seat.
P.45
2. Remove the bolt.
3. Remove the prongs from the grommets.
❙
Installation
1. Insert the prongs into the grommets.
2. Install the bolt.
3. Install the seat properly.
Left
Prongs
Grommets
Bolt
Right
Bolt
Prongs
Grommets
